The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments (1879)

Master Car Builders' Association, Forney, Matthias N. (Matthias Nace), 1835-1908, Garey, Leander, Smith, Calvin A · New York : The Railroad Gazette · leaf 226

An illustration from The car-builder's dictionary: an illustrated vocabulary of terms which designate American railroad cars, their parts and attachments, 1879, leaf 226
Freight Cars. 206 Fig. 19. Fig. SO. Eight-wheeled Gondola-car. Flat-car. 1. Stake-pocket. 1. Stake-pocket. … Fig. 22. Fig. 21. 'Tank or Oil Car. Flat-car, with Stakes. 1. Stake. 2. Stake-rest. 3. Stake-hod:;.

Railroad cars

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
