Card grinding in theory and practice : a treatise upon the various methods of grinding card clothing used by spinners of cotton, wool, silk, and other textile fibres (1922)

Dronsfield Brothers Ltd · Oldham [Lancashire] : Dronsfield Brothers · leaf 46

An illustration from Card grinding in theory and practice : a treatise upon the various methods of grinding card clothing used by spinners of cotton, wool, silk, and other textile fibres, 1922, leaf 46
Fig. 24. Patent Flat Clipping Machine No. 30. Code word— C lipije r. CARD MOUNTING. REVOLVING FLATS. 43 … the flat-face, and to accomplish this two movable cramps aresupplied with the machine ; these cramps, of which one isshewn in position, are placed over the flat and exert pressureupon the same, forcing the flat well home and leaving the clipsupstanding on both sides of the flat ; it may be…

Carding-machines · Textile machinery

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
