The carpenter's and joiner's hand-book: containing a complete treatise on framing hip and valley roofs. Together with much valuable instruction for all mechanics and amateurs, useful rules, tables, etc. ... Illustrated by thirty-seven engravings (1863)
Holly, H. W. (Henry Wells) · Norwich, Conn., Published by H. W. Holly · leaf 34
Fig. 18. Let a h c (Fig 18) be the given points.Upon each, of these points sweep the partsof circles, cutting each other, as shown in thefigure; draw the straight lines d d, and wherethey intersect each other will be the centrerequired. This method may be employedto find the centre of a circle… … Let a and o (Fig. 19) be the given circles.Place the diameter of each at right angles tothe other as at 3, connect the ends at c andd, then c d will be the diameter of thecircle required. 23. To find the form of a raking crownmoulding.
Carpentry
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
