ib^ M FhiU 70. … STAIR-CASING. 105 PLATE LXX. To diminish the Step of a Stair winding round one of the Quarters to a level Landing. Find the stretch-out round half the circular part of the rail, as directed for the foregoingplates, and complete the falling mould as directed in the last plate, for the winding part…
