t A, take its height b c, and place itfrom b to c at C and D; then take the whole diameter of the arch A, that is, twice the radiusa c, and place it from the crown of the other arches perpendicular to their bases from c to bat C, and from c to d at D; then the arch may be drawn as in plate 8, by… … Fig. 2.
