ROOFS. 63 PLATE 48. This Plate presents a design for an arched roof of very great span. It may extend asmuch as one hundred and twenty feet, or even more, with safety, if the buttresses are verystrong. The arch is made by bending stout planks to the desired curve, and bolting themtogether, which…
