The carpenter's new guide; a complete book of lines for carpentry and joinery, treating fully on practical geometry, soffits, groins, niches, roofs, and domes, and containing a great variety of original designs. Also a full exemplification of the theory and practice of stair building, cornices, mouldings, and dressings of every description. Including also some observations and calculations on the strength of timber (1854)
ordinates a h, c d, e f, &c., and then mark out thecap for the rail according to the letters. To draxo the Form of the Gap ; the Mitre to come to the Centre. Fig. 2. In every case draw the lines which are perpendicular to the diameter of therail, to the mitre; and then, with the apex of the… … Plate 64
Carpentry
