The carpenter's new guide; a complete book of lines for carpentry and joinery, treating fully on practical geometry, soffits, groins, niches, roofs, and domes, and containing a great variety of original designs. Also a full exemplification of the theory and practice of stair building, cornices, mouldings, and dressings of every description. Including also some observations and calculations on the strength of timber (1854)
will be the projection of the rail before it; then draw a dotted line to touch thenose of the scroll, parallel with d h, the longest side of the pitch-board; then will the distancebetween m and n be the thickness required. Much lighter stuff may be used, by gluing apiece on the under side, as shown…
Carpentry
