Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ... (1857)

Bell, William E · Philadelphia : Howard Challen · leaf 101

An illustration from Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ..., 1857, leaf 101
WMZ^j^S \ ThcnXcimltaTdt «Son.Phib 0 PLATE 15. CIRCULAR CENTRES. Plate 15 exhibits several designs, more or less convex, for the con-struction of centres, which are skeletons used by stone and brickmasons to build an arch upon, but which are to be taken away whenthe arch is sprung and the mortar…

Carpentry · Bridges

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
