Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ... (1857)

Bell, William E · Philadelphia : Howard Challen · leaf 134

An illustration from Carpentry made easy, or, The science and art of framing, on a new and improved system : with specific instructions for building balloon frames, barn frames, mill frames, warehouses, church spires, etc., comprising also a system of bridge building, with bills, estimates of cost, and valuable tables ..., 1857, leaf 134
2 is very similar in design to Fig. 1, in the preceding Plate,the principal difference consisting in having king and queen postsinstead of supporting rods. Fig. 3 shows the ridge pole supported by braces from the ends ofthe straining beam. The king post is, therefore, omitted; and theBpace between… … mft. Fuf.Z.
