used in construction (continued) No. 8. Shows the lap Joint used for splicing twopieces lengthwise. It needs to be nailed or boltedto prevent pulling apart. No. 9. A middle lap Joint. No. 10. Dovetail lap or lap dovetail. Thisform resists pulling apart and is a combinationof lap and dovetail…
