The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 56

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 56 — No. ji. At Edge of Tread. No JI. At Edge of Tread. … No. 3j. Ys In. Below Tread. No, 54. ^ In, Below Tread. MICROPHOTOGRAPHS OF SCHOEN STEEL WHEEL, 88 DIAMETERS, 51

Railroad cars

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
