The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 58

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 58 — No. 3j. Ys In. Below Tread. No, 54. ^ In, Below Tread. MICROPHOTOGRAPHS OF SCHOEN STEEL WHEEL, 88 DIAMETERS, 51 … No. 37. At Outer Edge of Tread. No. 38. ^ In. Below Outer Edge of Tread. MICROPHOTOGRAPHS OF SCHOEN STEEL WHEEL. 88 DIAMETERS 53 T HE SHELLED-OUT WHEEL.A POSSIBLE EXPLANATION OFTHE CAUSES OF WHEEL ANDTIRE FAILURES. The service that can be expected from any wheeldepends on the soundness and…

Railroad cars

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
