The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 74

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 74
No. 53. Slag Crack Near Edge in No. 54. Slag % In. BiiLuw 1 kiiad in Solid Metal. Solid Metal. MICROPHOTOGRAPHS OF SHELLED-OUT TIRE D. 50 DIAMETERS. 67 … No. 59. Structure at Edge of Tread. No. 60. Slag at Center of Tread. MICROPHOTOGRAPHS OF SHELLED-OUT WHEEL E. 50 DIAMETERS. 69

Railroad cars
