The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 85

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 85 — « 4* 12 3 4 CONTACTS OF 35-IN. STEEL-TIRED WHEEL UNDER CAF£ CAR.WEIGHT ON WHEEL, 6,075 LBS. 79 … CONTACTS OF 33-INCH WORN CAST IRON WHEEL UNDER GONDOLA CAR.WEIGHT ON WHEEL, 14,575 LBS. €ii»

Railroad cars

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
