The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 89

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 89 — 80,000 Lbs. Av. Pressure per Sq. In. 137,288 Lbs. Area .59 Sq. In. 90,000 Lbs. Av Pressure per Sq. In. 135,757 Lbs. Area .66 Sq. In 100,000 Lbs Av Pressure per Sq. In. 138,888 Lb»> Area 72 Sq. In … 110,000 Lbs. Av. Pressure per Sq. In. 137,500 Lbs Area .80 Sq. In.

Railroad cars
