The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 51

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 51 — DIAGRAM ILLUSTRATING GRAIN STRUCTURE OF SCHOEN STEEL WHEEL. … INTERPRETATION OF GRAIN STRUCTURE IN SCHOEN WHEEL AT VARYINGDISTANCES BELOW SURFACE OF TREAD. 48

Railroad cars

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
