The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 68

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 68 — . Ys In. Below Tread of Solid No. 44. i^ In. Below Tread of Solid Metal. Metal. MICROPHOTOGRAPHS OF SHELLED-OUT TIRE C. 50 DIAMETERS. 63 … No. 45. At J^ In. Below Shelled-outSpot. No. 46. Slag Crack in Solid SectionOF Tire.

Railroad cars
