The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 72

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 72
No. 53. Slag Crack Near Edge in No. 54. Slag J^ In. Below Tre. Solid Metal. Solid Metal. MICROPHOTOGRAPHS OF SHELLED-OUT TIRE D. 50 DIAMETERS. 67 … No. 55. At Edge of Shelled-oit Section. No. 56. Yia In. Below Tread of Shelled-out Section.

Railroad cars
