The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 83

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 83 — # CONTACTS OF 35-IN. STEEL-TIRED WHEEL UNDER CAFt CAR.WEIGHT ON WHEEL, 6,075 LBS. … CONTACTS OF 33-INCH WORN CAST IRON WHEEL UNDER GONDOLA CAR.WEIGHT ON WHEEL, 14,575 LBS. «l»

Railroad cars
