The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 92

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 92 — 80,000 Lbs. Av. Pressure per Sq. In. 126,983 Lbs. Area .63 Sq. In. 85,000 Lbs. Av. Pressure per Sq.In. 116,666 Lbs Area .72 Sq. In. 90,000 Lbs- Av Pressure per Sq. In. 121,621 Lbs. Area .74 Sq. In. … 95,000 Lbs Av. Pressure per Sq. In. 121,794 Lbs. Area 78_Sq. In. 100,000 Lbs. Av, Pressure per Sq. In. 120,481 Lbs. Area .83 Sq. In. 105,000 Lbs. Av. Pressure pe^ Sq. In. 117,977 Lbs. Area .89 Sq In.

Railroad cars
