The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 93

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 93 — 110,000 Lbs. Av. Pressure per. Sq. In. 118,279 Lbs. Area .93 Sq. In. 115,000 Lbs. Av. Pressure per- Sq. In. 116,161 Lbs. Area .99 Sq. In. 120,000 Lbs. Av. Pressure per Sq In. 115,384 Lbs. Area 1.04 Sq.In. CONTACTS BETWEEN 33-IN. CAST IRON WHEEL AND lOQ-LB. RAIL. … 125,000 Lbs. Av. Pressure per Sq. In. 119,047 Lbs. Area 1.05 Sq. In.
