Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 149
Fig. 487. -Conventional View showinggeneral Construction of Queen-post Roof Trusswith Hipped End. I the straining beam. The upper ends of I the queen-posts are cut to receive the purlins, as shown by the conventional view (Figs. 490 notched out part of its depth so as to fit inwith the purlins in… … Fig. 488.— Part Sectional Elevation on Line D D (Fig. 489) of Queen-post Truss with Hipped End.
Carpentry · Joinery
