Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 182
162 CARPENTRY AND JOINERY the outline of common rafters and bearers,as shown in Fig. 615 ; the truss is drawn tothe same shape, but within the outlines, asshown. It will be noticed that the truss atthe narrow end is a king-post truss, theremainder being queen-post trusses. Thecommon rafters, a few…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
