Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 191
. 647, where theplan of the plates at a makes an obtuse bevel shown at m is for application to theedges of the jack rafters. To obtain thedevelopment of the hip end agb, producea b and draw x y at right angles ; projectfrom G, and make x g equal to e f. Joing to h, so obtaining the inclination of… … Fig. 647.—Method of obtaining Bevels for Feet and Side Cuts, and also the Backing of Hips. angle, and at B an acute angle, and the planof the hips does not bisect the angles, theyoften cannot get a correct result, althoughthe geometrical principles are similar, aswill be shown. At cde set up the…
Carpentry · Joinery
