Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 20
Fig. 18.—Mitre Shooting Block. Plumb Rule and Square.—The plumb rule(Fig. 23) is used by the carpenter and fixerfor testing the vertical position of piecesof timber, framing, doorposts, sash frames,etc., which should be fixed upright. Theplumb square (Fig. 24) is useful for testing HAND TOOLS AND… … worker and by the kind of work to be done.A joiners bench of the usual patternis shown by Fig. 25. It is 12 ft. long, by2 ft. 6 in. wide, and 3 ft. high. The legsare 4 in. by 4 in. ; bearers and rails, 4 in. by Fig. 19.—Donkeys-ear Shooting Block. h—3^2—-
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
