Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 274
Fig. 831.—Conventional View of Joints at E (Fig. 824), Fig. 830. Fig. 828.—Conventional View of Joints between Ribs and Strut at B (Fig. 824). Fig. 829.—Conventional View of Joints at C (Fig. 824). Fig. 830.—Conventional View of Joints at D (Fig. 824). 11* ARCH CENTERINGS. Setting Out for Segmental…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
