Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 29
Fig. 65.—Rebate Plane. true and even. There are also employedovolo lambs - tongue planes for form-ing the mouldings on sash stiles and Fig. 63.—Iron Mouth-piece forSmoothing Plane. straight mouldings of all kinds, but machineryhas of late years been increasingly usedfor such work. Small planes of… … Fig. 66.Figs. 66, 67, and 68.—Bead Plane. Fig. 68. rails. The sash fillister (Fig. 74) is generallyused for making rebates adjacent to theback side of the stuff, its fence workingagainst the face side. When rebates haveto be made next to the face side of thework a side fillister (Fig. 75) is most…
Carpentry · Joinery
