Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 314
Fig. 934.—Conventional View showing Connection of Secondary Rib with Main Ribs, and Method of Lagging Centering. same centre, thus they can be cut from one same distance, as indicated at b and c (Fig.mould by a bandsaw, then notched down 934). The construction of a secondary ribon the ribs so that… … »»»* JOINERS RODS. Introduction.—A rod stands in the samerelation to a craftsman as a scaled drawingdoes to a designer. In most shops the workis done by a setter-out, who makes hisdrawings from full-sized details preparedby the architect. The most convenient sizeof rod for general use is about 10…
Carpentry · Joinery
