Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 330
ght rebate on the top edge, outside, toreceive the lead dressing ; and form themoulding on the top rail at e, allowing 3|in. for the width. Note that the top rail isgrooved for the glass instead of being rebated(as is usual) at the sides. The bottom rail includes the thickness of the rough… … Fig. 985.—Detail showing Method of Fixing Bar to Bottom Rail. should carry about the same line of sight asthe moulding vertically ; it will thereforeproject 2 in. on the horizontal line. Indicateroughly the depth of the joist, and showboarding and lead to flat. Divide the spaceat the spandril end,…
Carpentry · Joinery
