Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 332
Fig. 991. Detail of Angle Stile to ChimneyBreast. 9 in. deep. Fill in a line f- in. from thechimnev breast to represent the face of theplaster at b. Next draw a line parallel withthe edge of the rod, and J in. from the faceof the plaster b, to represent the face of thecupboard framing c. Draw a… … 1| in. from the last,to represent 1J in.front, finishing theline on right-handside at the brick-work, and on theleft-hand side at theface of the plaster.Fill in the stile andangle bead d with themould seen at Fig.991. The stiles mustbe set out to thefigured dimensions.The doors are hungfolding in…
Carpentry · Joinery
