Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 347
Fig. 1056. -Joint between Post and Head ofFrame. … Fig. 1057. Showing Top of Post Set Out fromRod. Hanging and Fastening. This form of door would be hung with4-in. to 5-in. wrought butt hinges,the lower one being fixed about 11 in. from the bottom, so that the screws should notbe too near a tenon, the top butt being6 in. or 7 in. down. Doors of…
Carpentry · Joinery
