Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 364
Fig. 1122.—Showing an Angle of Jambs withSolid Stops. to the posts and head, so that their facesare flush with the edges of the jamb, as in-dicated at Fig. 1119. These grounds aregenerally splayed at the back edges as illus-trated, to form a key for the plastering. In CARPENTRY AND JOINERY … HALF TIMBERED PORCH AND ENTRANCE DOORWAY DOORS AND DOOR FRAMES. 337 the case of commoner work, instead of pre-paring and fixing grounds, pieces of board,2 in. or 3 in. wide and 1 ft. or so long, arefixed at intervals of 12 in. or 15 in., as indi-cated at h and d (Fig. 1119). This exampleshows the…
Carpentry · Joinery
