Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 381
Fig. 1163.—Enlarged Conventional Details of Corner of Sash, showing it fitted to Framing of Door. :;:>2 CARPENTRY AND JOINERY. Frame, Linings, Grounds, etc.—The con-struction of the frame being similar to pre-vious examples, it will not be necessary toenter into a lengthy description of it. Itis… … Fig. 1164.—Conventional Detail showing ThumbScrew, etc., for Fastening Bottom of Shutter. (Figs. 1157 and 1159), and in an enlargeddetail (Fig. 1160). In this case the groundshave ovolo-moulded edges, and are slightlyrebated so as to fix to the outer edges of thelinings, as shown at a (Fig. 1160).…
Carpentry · Joinery
