Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 381
Fig. 1164.—Conventional Detail showing ThumbScrew, etc., for Fastening Bottom of Shutter. (Figs. 1157 and 1159), and in an enlargeddetail (Fig. 1160). In this case the groundshave ovolo-moulded edges, and are slightlyrebated so as to fix to the outer edges of thelinings, as shown at a (Fig. 1160).… … Fig. 1165. Stub and Plate for Securing Top ofShutter. the same time produces an effect equal to abroader architrave moulding. Door.—The construction of this door issimilar in some respects to those alreadydescribed, and therefore these points neednot be recapitulated. However, as in the setting out…
Carpentry · Joinery
