Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 397
Fig. 1214.—Shoulders Set Out on MouldedEdge. the depth the ovolo works down ; then gaugeJ in. for the last 3 in., equal to the depth therebate is worked down for the doors ; theseshould be accurately cut away down to thegauge lines, then the slip will have theappearance shown in Fig. 1216. Lay… … Fig. 1213.—Application of Slip for Setting OutShoulders to fit to Rebates. it wTill only be necessary to explain the newfeatures. Only the sight lines, not theshoulders, may be taken from the rod. Thesight lines are the distances between theintersection of the square part of theframe as indicated…
Carpentry · Joinery
