Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 397
tes. it wTill only be necessary to explain the newfeatures. Only the sight lines, not theshoulders, may be taken from the rod. Thesight lines are the distances between theintersection of the square part of theframe as indicated at a in Figs. 1212 and1213. Then by means of a prepared slip,mark out… … Fig. 1215.—Shoulder Set Out for RebatedEdge. with the knife the line to cut off at bottom,mark off above this 7 ft. (the height oftransom rail), then 2J in. (the finished thick-ness of transom rail) ; above this mark1 ft. 6 in., and the head is reached. Markthe other jamb and the two mullions…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
