Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 413
th full-size sections ofmouldings and panels, which are generallysupplied by leading architects. If thebuilding is sufficiently advanced, it is well to test between the reveals and the spring-ing, in case any slight discrepancy hasoccurred in the dimensions between themasonry and the drawings. From… … Fig. 1260. -Enlarged Detail of Upper Part ofVertical Section (Fig. 1258). of the woodwork should be set out for theheights as at Fig. 1258. For the framing,the head and fanlight, the linings and archi-traves, a board should be used large enoughto strike out the main lines of each of these ;and it…
Carpentry · Joinery
