Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 416
Fig. 1261.—Conventional Detail of Joints, etc., of Post, Head, and Transom. cutting(not shoulders) having beeia pattern of the moulds, made of a piece ofhardwood or zinc, should be marked onthe ends of the several pieces. If machineryis at hand, the mouldings would be stuckby it, and would only… … Fig. 1262.—Enlarged Section through Lower PanelMoulding. Door Post, etc. 386 CARPENTRY AND JOINERY. be described in a later section. Sometimesthese circular heads are built up of two thick-nesses, the joint taking place in a line withthe stop part of the rebate. One layer isformed of one more piece…
Carpentry · Joinery
