Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 427
ted Readyfor Bolting to Posts. in position by beads, which generally wouldbe prepared out of the solid stuff. Doors.—The curvature of the doors inplan being an arc of only about 2-in. rise,all the panels and rails would be preparedout of the solid. The sections of these aregiven in Figs. 1274 to… … Pig. 1287.—Conventional View showing the General Construction of Transom and Cornice,and the Intersection with Stonework and Door Post. Fig. 1289.
Carpentry · Joinery
