Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 428
Fig. 1290. Fig. 1291. Fig. 1290. Fig. 1291. -Elevation of Circle-on-Circle Door andFrame. Section of Circle-on-Circle Door Frame. … Fig. 1292.—Plan of Circle-on-Circle Door Frame. 398 CARPENTRY AND JOINERY. as a rule, it [would be found only inbuildings of rather ordinary class. Itwill be seen by the plan that the jambsof the I parts do not radiate; the innerarris of the soffit of the arch is a semi-circle, and thus, on account…
Carpentry · Joinery
