Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 459
Fig. 1395.—Detail of Joints at Bottom of Framingsat Transom and Head. This is shown at Figs. 1392 and 1396.The under surface of the head of the frame,it will be noticed, is splayed a little. Thisis to allow the bead marked b, which hasto be nailed to the top rail of the sash, toclear the head of… … -Detail of Joints in Top Sash. ; Old-style Casement Windows. Figs. 1401 and 1402 are respectively sec-tions through the jamb, head, and sill ofa solid casement frame, sunk flush with theface of a stone wall, which is duly checked
Carpentry · Joinery
