Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 461
ase ; here the frame projects beyond theface of the wall. A j-in. check or rebateis made all round the inner edge of theframe, and the joint in this case should bemade with red-lead and oil. The frame issecured by wrought-iron forked angle-tiessunk flush into the back face of the frameand built… … Fig. 1407. Fig. 1408. Fig. 1407.—Outside Elevation of Small CasementWindow. Fig. 1408.—Vertical Section of Small CasementWindow. Fig. 1409.—Horizontal Section of Small CasementWindow. the stone. The bracketing for the cornicemay either be built into the wall, which isadvisable if hardwood is…
Carpentry · Joinery
