Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 484
ightb, c and d (Fig. 1466). When gauging forthe mortices and tenons for the intersec-tion of the bars, it should be noted that themortices and tenons are thinner where thebars intersect than where they join thestiles and rails. This is shown at b and e(Fig. 1473), and also where the bars are setout… … 6x2!4 &A* Fig. 1471.—Enlarged Detail of Vertical Sectionat A, B, and C (Fig. 1468) 452 CARPENTRY AND JOINERY.
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
