nt roll is driven from thetwist gear, as already described, but when it runs in, motion is com-municated to the front roll, from the carriage shaft, through the gearsof twenty-two, fifty and seventy teeth (Fig. 222) by the pawl engagingthe teeth of the roller motion gear. 329 288 COTTON SPINNING…
