Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 493
Fig. 1499.—Conventional View of Partof Stile and Head of Top Sash. Fig. 1500.—General View of Cylinder. … Fig. 1501.—Connecting Architrave and Plinthwith Slip Dovetail Tenon. -Method of Connecting Architrave andPlinth by Dovetail Lapping. d, e, I (Fig. 1492). The joints, and por-tions of the head and the stile showingthe joint at the crown separately, areshown at a, b, and c (Fig. 1499). The…
Carpentry · Joinery
