Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 52
ual rings. When it is required to obtainoak panels, etc., showing the beautifulmarkings of the medullary rays, the timber TIMBER. 37 should be cut as shown at Fig. 147. Byarranging boards as in Fig. 148 a betterjoint is made than that shown at Fig. 149.When mouldings are prepared from woodwhich has… … Fig. 150.—Shrinkage of Moulding. open mitre as shown, although the work-manship may be first rate. Fig. 151 showsthe best arrangement, the annual rings beingat right angles to the breadth. Cutting Strongest Beam from RoundLog. By mathematical investigation Fig. 152shows the graphic method of…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
