Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 539
he backof the rail of the framed and panelledjamb as shown at c (Figs. 1656 and 1659).The jambs are then fixed in position byscrewing the dovetail ends to the groundsas shown at d (Figs. 1657 and 1658)..The portions of the stiles forming therebates, having been prepared with slots Fig.… … SKIRTINGS, DADOS, PANELWORK, LININGS, ETC. 505
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
