Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 572
ion is taken through the crownof the soffit of the arch, giving sectionsof the head of the frame, the fanlight, the jambs at each end are also similarly con-nected to the ground G. The centraljambs are hollowed and moulded for thehanging stiles of the swing doors. Theother jambs are rebated for the… … Fig. 173C. Fig. 1731. Fig. 1730.—Enlarged Vertical Section through Centre of Pilasters (Fig. 1725). Fig. 1731.—Vertical Section through Centre of Swing Door (Fig. 1725). Fig. 1732.—Enlarged Detail of a Portion of Swing Door, Pilaster, Cornice, and Fixed Door. 536 CARPENTRY AND JOINERY. moulded and…
Carpentry · Joinery
