Cassells' carpentry and joinery (1907)
Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 74
Fig. 209. Fig. 208.—Birds-mouth Joint between Strut andStraining Piece, or Head. Fig. 209.—Mitre Butt Joint between StrainingPiece and Strut. Fig. 207.—Toe Joint with Tenon. Fig. 210.—Dovetailed Halving Bolted.Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
